Wieght
13.20 KG
-
Frame
Genius Carbon / IMP technology / HMF Mainframe
BB92 / Alloy SL 6011 swingarm
Virtual 4 Link Design
27.5 (2.6 & 2.8) and 29 (2.4 & 2.6) tire compatible with Geo -BB adj.
SW dropouts for Boost 12x148mm
TBC Trunnion box construction
-
Fork
FOX 34 Float Performance Air
Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
Reb. Adj. / Lockout / 150mm travel
-
Remote System
SCOTT TwinLoc Suspension System
TSP Suspension - Seatpost Remote
below Bar / 3 modes / integ. Grip clamp
-
Shock Rear
FOX NUDE EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout - Traction Control -Descend
DPS / Reb. Adj.
Travel 150 - 100 - Lockout / 185X55mm
-
Headset
Syncros FL2.0 Press Fit E2 / Tapered 1.5" - 1 1/8"
OD 50/62mm / ID 44/56mm
-
Derailleur ( Rear )
Sram GX / Eagle 12 Speed
-
Derailleur ( Front )
SCOTT Chainguide
-
Brakes
Shimano SLX M7000 Disc
180mm F & R / SM-RT64 CL Rotor
-
Shifters
Sram GX Trigger
-
Crankset
Sram X1 1000 Eagle GXP Boost PF
QF 168 / 32T
-
BB-Set
Sram GXP PF integrated / shell 41x92mm
-
Handlebars
Syncros FL1.5 mini Riser / Alloy 7050D.B.
12mm rise / 9° / 760mm
Syncros Pro lock-on grips
-
H'stem
Syncros FL1.5 / Alloy 2014
integrated Spacer & Top Cup / 31.8mm / 6° / 1 1/8"
-
Seatpost
FOX Transfer Dropper Remote
31.6mm / S size 100mm / M 125mm / L & XL 150mm
-
Seat
Syncros XM2.0 / CRMO rails
-
Hub ( Front )
Syncros TR2.5 CL
F: 15x110mm, R: 12 x 148mm Boost
30mm Tubless ready rim 28H / XD
-
Hub ( Rear )
Syncros TR2.5 CL
F: 15x110mm, R: 12 x 148mm Boost
30mm Tubless ready rim 28H / XD
-
Chain
Sram CN GX Eagle
-
Cassette
Sram GX / XG1275 / 10-50 T
-
Tires
700 Series: Maxxis Rekon 2.80 x 27.5
120TPI Kevlar Bead / EXO / TR Tubeless ready
Front: 3C Maxx Terra / Rear: 3C Maxx Speed
900 Series: Schwalbe Nobby Nic 2.6 x 29
EVO / Snake Skin / TL-Easy / Addix Speedgrip
