Wieght
14.30 KG
-
Frame
Genius Alloy SL 6011
custom butted / Virtual 4 Link Design
27.5 (2.6 & 2.8) and 29 (2.4 & 2.6) tire compatible with Geo -BB adj.
TBC Trunnion box construction / Boost 12x148mm
-
Fork
FOX 34 Float Performance Air
Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
Reb. Adj. / Lockout / 150mm travel
-
Remote System
SCOTT TwinLoc Suspension System
TSP Suspension - Seatpost Remote
below Bar / 3 modes / integ. Grip clamp
-
Shock Rear
FOX Float EVOL Performace Trunnion
3 modes / Lockout - Trail - Descend
DPS / Reb. Adj.
Travel 150mm / 185X55mm
-
Headset
Syncros Pro Press Fit E2 / Tapered 1.5" - 1 1/8"
OD 50/62mm / ID 44/56mm
-
Derailleur ( Rear )
Sram GX / Eagle 12 Speed
-
Derailleur ( Front )
SCOTT Chainguide
-
Brakes
Shimano MT500 Disc
180mm F & R / SM-RT54 CL Rotor
-
Shifters
Sram GX Trigger
-
Crankset
Sram X1 1000 Eagle GXP Boost PF
QF 168 / 32T
-
BB-Set
Sram GXP PF integrated / shell 41x92mm
-
Handlebars
Syncros FL2.0 mini Riser / Alloy 6061D.B.
12mm rise / 9° / 760mm
Syncros Pro lock-on grips
-
H'stem
Syncros FL2.0 / 6061 Alloy
6° / integrated Top Cup / 31.8mm / 1 1/8"
-
Seatpost
Syncros Dropper 2.0 / Remote
31.6mm / S size 100mm / M 125mm / L & XL 150mm
-
Seat
Syncros XM2.0 / CRMO rails
-
Hub ( Front )
Formula CL811 / 15x110mm
-
Hub ( Rear )
Formula CL14811 / Boost 12x148mm / XD
-
Chain
Sram CN GX Eagle
-
Cassette
Sram GX / XG1275 / 10-50 T
-
Spokes
Stainless Black 15G / 1.8mm
-
Rims
Syncros X-30S / 32H / 30mm / Sleeve Joint
Tubeless ready
-
Tires
700 Series: Maxxis Rekon2.80 x 27.5
60TPI Kevlar Bead / TR /Dual compound
900 Series: Schwalbe Nobby Nic 2.6 x 29
Performace / TL-Easy / Addix
