Wieght
13.10 Kg
-
Frame
Scale 700 Alloy
Custom Butted Superlight Tubing / Tapered HT
BB92 / 3.0" Tire clearance / Full Internal Cable Routing
IDS SL DM dropouts for 12x148mm Boost
-
Fork
Suntour XCR RL-R / Coil Spring
15 x110mm QR axle / Tapered Steerer / Reb. Adj
Remote Lockout / 120mm travel
-
Remote System
Suntour Remote
-
Headset
Syncros OE Press Fit / Tapered 1.5" - 1 1/8"
OD 50/61mm / ID 44/55mm
-
Derailleur ( Rear )
Sram NX1 / 11 Speed
-
Brakes
Shimano M365 Disc
180/F and 160/Rmm SM-RT30 CL Rotor
-
Shifters
Sram NX1 Trigger
-
Crankset
Sram NX1 GXP Boost PF
30T
-
BB-Set
Sram GXP PF integrated / shell 41x89.5mm
-
Handlebars
Syncros FL2.0 mini Riser / Alloy 6061D.B.
12mm rise / 9° / 740mm
-
H'stem
Syncros 6061 Alloy
oversize 31.8mm / 1 1/8" / 6° angle
-
Seatpost
Syncros / 31.6x400mm
-
Seat
Syncros XM2.5
-
Hub ( Front )
Formula CL811 / 15x110mm
-
Hub ( Rear )
Formula CT1702 / 5x141mm
-
Chain
Sram PC1110
-
Cassette
Sram PG1130 / 11-42 T
-
Spokes
Stainless Black 15G / 1.8mm
-
Rims
Syncros X-30S / 32H / 30mm / Sleeve Joint
Tubeless ready
-
Tires
Maxxis Rekon / 2.80x27.5 / 60TPI Kevlar Bead
TR Tubeless ready
