Wieght
10.30 Kg
-
Frame
Scale 3 Carbon / IMP technology / MF
BB92 / SW DM dropouts for Boost 12x148mm
SDS2 advanced Shock & Standing Damping System
ICCR Cable routing
-
Fork
FOX 32 SC Float Performance Air
Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
Lockout / Reb. Adj. / 100mm travel
-
Remote System
SCOTT RideLoc Remote Technology
3 modes / integ. clamp
-
Headset
Syncros Pro Drop in / Tapered 1.5" - 1 1/8"
bearing diameter size 42mm and 52mm
-
Derailleur ( Rear )
Shimano XT RD-M8000 SGS
DM / Shadow Plus / 22 Speed
-
Derailleur ( Front )
Shimano XT FD-M8020-D / side swing
-
Brakes
Shimano XT M8000 Disc
180/F and 160/R mm SM-RT64 CL Rotor
-
Shifters
Shimano XT SL-M8000-I / Rapidfire Plus
2 way release / Ispec 2 clamp
-
Crankset
Shimano XT FC-M8000-B2 / Hollowtech 2
34x24 T
-
BB-Set
Shimano BB-MT500-PA / shell 41x92mm
-
Handlebars
Syncros FL1.5 T-Bar / Alloy 7050 D.B.
T shape Flat / 9° / 720mm
Syncros Pro lock-on grips
-
H'stem
Syncros FL1.5
6° / integrated Spacer & Top Cup
2014 Alloy / 31.8mm / 1 1/8"
-
Seatpost
Syncros FL1.5 / 10mm offset
31.6 x 400mm
-
Seat
Syncros XR1.5 / Titanium rails
-
Hub ( Front )
Syncros XR2.5 CL
F: 15x110mm, R: 12 x 148mm Boost
25mm Tubless ready rim / 28H / XD / DT RWS
-
Hub ( Rear )
Syncros XR2.5 CL
F: 15x110mm, R: 12 x 148mm Boost
25mm Tubless ready rim / 28H / XD / DT RWS
-
Chain
Shimano CN-HG601-11
-
Cassette
Shimano SLX CS-M7000 / 11-42 T
-
Tires
Schwalbe Rocket Ron EVO / 2.25
127EPI Kevlar Bead / Tubeless Easy
Addix Speed compound
