Wieght
9.70 Kg
-
Frame
Scale RC Carbon / IMP technology / HMX
1x optimized / BB92 / SW dropouts for Boost 12x148mm
SDS2 advanced Shock & Standing Damping System
ICCR Cable routing
-
Fork
FOX 32 SC Float Performance Air
Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
Lockout / Reb. Adj. / 100mm travel
-
Remote System
SCOTT RideLoc Technology / below bar remote
3 modes / integ. Grip clamp
-
Headset
Syncros Pro Drop in / Tapered 1.5" - 1 1/8"
Bearing diameter size 42mm and 52mm
-
Derailleur ( Rear )
Sram X01 / Eagle 12 Speed
-
Derailleur ( Front )
SCOTT Chainguide
-
Brakes
Sram Level TL Disc / tool free reach adj
180/F and 160/Rmm Centerline Rotor
-
Shifters
Sram GX Trigger
-
Crankset
Sram X1 Carbon Eagle GXP Boost PF
QF 168 / 32T
-
BB-Set
Sram GXP PF integrated / shell 41x92mm
-
Handlebars
Syncros FL1.5 T-Bar / Alloy 7050 D.B.
T shape Flat / 9° / 720mm
Syncros Pro lock-on grips
-
H'stem
Syncros XR1.5 -8°
Integrated Spacer & Top Cup
2014 Alloy / 31.8mm / 1 1/8" / Garmin mount
-
Seatpost
Syncros FL1.5 / 10mm offset
31.6 x 400mm
-
Seat
Syncros XR1.5 / Titanium rails
-
Hub ( Front )
Syncros XR2.0 6 Bolt
F: 15x110mm, R: 12 x 148mm Boost
25mm Tubless ready rim 28H / XD / DT RWS
-
Hub ( Rear )
Syncros XR2.0 6 Bolt
F: 15x110mm, R: 12 x 148mm Boost
25mm Tubless ready rim 28H / XD / DT RWS
-
Chain
Sram CN GX Eagle
-
Cassette
Sram GX / XG1275 / 10-50 T
-
Tires
Maxxis Aspen / 2.25 / 120TPI Kevlar Bead
TR Tubeless Ready / EXO / 3C maxx Speed
