Wieght
12.10 Kg
-
Frame
Spark 3 Carbon / IMP technology / HMX
BB92 / Carbon swingarm
SW DM dropouts for Boost 12x148mm
TBC Trunnion box construction
-
Fork
FOX 34 Float Factory Air / Kashima
FIT4 3-Modes with low Speed adj. / 15x110mm QR axle
tapered steerer / Reb. Adj. / Lockout / 120mm travel
-
Remote System
SCOTT TwinLoc Remote Technology
3 modes front and rear / integ. Grip clamp
-
Shock Rear
FOX NUDE EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout - Traction Control -Descend
DPS / Kashima / Reb. Adj.
Travel 120 - 85 - Lockout / 165X45mm
-
Headset
Syncros FL1.5 Drop in / Tapered 1.5" - 1 1/8"
Ti bearing diameter size 42mm and 52mm
-
Derailleur ( Rear )
Shimano XT Di2 RD-M8050 GS
DM / Shadow Plus / 22 Speed
-
Derailleur ( Front )
Shimano XT Di2 FD-M8070
with SM-M905-D Adaptor
-
Brakes
Shimano XT M8000 Disc
180mm F & R / SM-RT64 CL Rotor
-
Shifters
Shimano XT Di2 SL-M8050-I Electronic shift switch
Ispec 2 clamp
-
Crankset
Shimano XT FC-M8000-B2 / Hollowtech 2
34x24 T
-
BB-Set
Shimano SM-BB71-41A / shell 41x92mm
-
Handlebars
Syncros FL1.0 Di2 Carbon T-Bar
T shape flat / 9° / 740mm
Syncros Pro lock-on grips
-
H'stem
Syncros FL1.5 / Alloy 2014
integrated Spacer & Top Cup / 31.8mm / 6° / 1 1/8"
Garmin mount
-
Seatpost
FOX Transfer Dropper Remote
Kashima / 31.6mm / S size 100mm / M, L & XL 125mm
-
Seat
Syncros XR1.5 / Titanium rails
-
Hub ( Front )
DT Swiss X1825 Spline CL
F: 15x110mm, R: 12 x 148mm Boost
25mm Tubless ready rim / 28H
DT RWS w/Removable Lever with Tool
-
Hub ( Rear )
DT Swiss X1825 Spline CL
F: 15x110mm, R: 12 x 148mm Boost
25mm Tubless ready rim / 28H
DT RWS w/Removable Lever with Tool
-
Chain
Shimano CN-HG601
-
Cassette
Shimano XT CS-M8000 / 11-42 T
-
Tires
Maxxis Forekaster / 2.35 / 120TPI Kevlar Bead
TR Tubeless Ready / EXO / 3C maxx Speed
