Wieght
13.80 Kg
-
Frame
FOX 34 Float Performance Air
Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
Reb. Adj. / Lockout / 120mm travel
-
Fork
FOX 34 Float Performance Air
Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
Reb. Adj. / Lockout / 120mm travel
-
Remote System
SCOTT TwinLoc Remote Technology
3 modes front and rear / integ. Grip clamp
-
Shock Rear
FOX NUDE EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout - Traction Control -Descend
DPS / Reb. Adj. / Travel 120 - 85 - Lockout / 165X45mm
-
Headset
Syncros Pro Press Fit / Tapered 1.5" - 1 1/8"
OD 50/61mm / ID 44/55mm
-
Derailleur ( Rear )
Shimano XT RD-M8000 SGS
DM / Shadow Plus / 22 Speed
-
Derailleur ( Front )
Shimano XT FD-M8020-D / side swing
-
Brakes
Shimano SLX M7000 Disc
180/F and 160/R mm SM-RT64 CL Rotor
-
Shifters
Shimano XT SL-M8000-B-I / Rapidfire Plus
2 way releaseIspec 2 clamp
-
Crankset
Shimano XT FC-M8000-B2 / Hollowtech 2
34x24 T
-
BB-Set
Shimano BB-MT500-PA / shell 41x92mm
-
Handlebars
Syncros FL2.0 T-Bar / Alloy 6061
T shape Flat / 9° / 740mm
Syncros Pro lock-on grips
-
H'stem
Syncros FL2.0 / 6061 Alloy
6° / integrated Top Cup / 31.8mm / 1 1/8"
-
Seatpost
FOX Transfer Dropper Remote
31.6mm / S size 100mm / M, L & XL 125mm
-
Seat
Syncros XR2.0 / CROM rails
-
Hub ( Front )
Syncros XR2.5 CL
F: 15x110mm, R: 12 x 148mm Boost
25mm Tubless ready rim 28H
-
Hub ( Rear )
Syncros XR2.5 CL
F: 15x110mm, R: 12 x 148mm Boost
25mm Tubless ready rim 28H
-
Chain
Shimano CN-HG601
-
Cassette
Shimano SLX CS-M7000 / 11-42 T
-
Tires
Maxxis Forekaster / 2.35 / 120TPI Kevlar Bead
TR Tubeless Ready / EXO / 3C maxx Speed
