Wieght
12.40 Kg
-
Frame
Spark RC Alloy SL 6011
custom butted Hydroformed tubes
tapered Headtube / BB92 / DM hanger
dropouts for 12x148mm
-
Fork
FOX 32 Float Rhythm
Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
Reb. Adj. / Lockout / 110mm travel
-
Remote System
SCOTT TwinLoc Suspension System / below Bar Remote
3 modes / integ. Grip clamp
-
Shock Rear
FOX Float Performace Trunnion
3 modes / Lockout - Trail - Descend
DPS / Reb. Adj.
Travel 100mm / 165X45mm
-
Headset
Syncros Pro Press Fit / Tapered 1.5" - 1 1/8"
OD 50/61mm / ID 44/55mm
-
Derailleur ( Rear )
Sram GX / Eagle 12 Speed
-
Brakes
Sram Level TL Disc / tool free reach adj
180/F and 160/Rmm Centerline Rotor
-
Shifters
Sram GX Trigger
-
Crankset
Sram X1 1000 Eagle GXP Boost PF
QF 168 / 32T
-
BB-Set
Sram GXP PF integrated / shell 41x89.5mm
-
Handlebars
Syncros FL2.0 T-Bar / Alloy 6061
T shape Flat / 9° / 720mm
Syncros Pro lock-on grips
-
H'stem
Syncros XR2.0 -8°
Integrated Spacer & Top Cup
6061 Alloy / 31.8mm / 1 1/8"
-
Seatpost
Syncros FL2.0 / 10mm offset
31.6 x 400mm
-
Seat
Syncros XR2.0 / CROM rails
-
Hub ( Front )
Syncros XR2.5 6 Bolt
F: 15x110mm, R: 12 x 148mm Boost
25mm Tubless ready rim / 28H / XD
-
Hub ( Rear )
Syncros XR2.5 6 Bolt
F: 15x110mm, R: 12 x 148mm Boost
25mm Tubless ready rim / 28H / XD
-
Chain
Sram CN GX Eagle
-
Cassette
Sram GX / XG1275 / 10-50 T
-
Tires
Maxxis Aspen / 2.25 / 60TPI Kevlar Bead
TR Tubeless Ready / Dual compound
